IR009B-D/IR009B-H Surface Mounted Door/Hand Sensor Switch

  • $4.50
Zoom image

IR009B-D/IR009B-H Surface Mounted Door/Hand Sensor Switch

  • $4.50
IR009B-D/IR009B-H Surface Mounted Door/Hand Sensor Switch:

Microwave Infrared Automatic Door Hand Wave Sensors Ir Door Sensor Switch for cabinet lights with DC plug

Email:sales@surmountor.com

      Product Parameters:

      Input Voltage 12-24V Dimension 8*9*17MM
      Current 4A Watt 48W(12V); 96W(24V)
      Detection Range 0.5cm≤Length≤10cm Certificated CE, RoHS
      Cable Length

      Input/output cable: 1m

      Detector cable length: 25cm with  DC5521 Plug

      		 Function
      • Hand Sensor IR009B-H: Automatically switch ON/OFF when hand pass over.
      • Door Sensor IR009B-D: Lights will be ON/OFF when you open/close the door.


      Connection Guidance:

      Door Sensor IR009B-D Product Description:

      • The LED lamp connects to the output end.
      • The IR sensor switch will turn on the LED light when the door is open and will turn off the LED light when the door is closed.
      • Detection range is 10cm from the sensor detector to the door.
      • The sensor switch will turn on or off the LED light with above repeatable steps.

      Door Sensor IR009B-D Product Installation:


      Hand Sensor IR009B-H Product Description:

      • The LED lamp connects to the output end.
      • The IR sensor switch will turn on the LED light when the hand pass over the detector within 10cm in distance and will turn off the LED light when the hand pass over the detector again.
      • The sensor switch will turn on or off the LED light with above repeatable steps.

      Hand Sensor IR009B-H Product Installation:


      Product Certificatation:

      Low Voltage 12V Mini Micro Smart Switch Automatic Turn Off Pir Sensors Dc 24V Infrared Pir Motion Sensor For Long Distance

      Relative micro PIR sensor motion sensor 12v/24v for led strip led aluminum profile

      Low Voltage 12V Mini Micro Smart Switch Automatic Turn Off Pir Sensors Dc 24V Infrared Pir Motion Sensor For Long Distance


      Packing & Delivery:

      Custom Packing and Custom Label are available as request !
